Click! - Modular LED Strip System

An innovative and effective strip lighting solution.  The Click! modular strip LED system facilitates stunning LED strip designs by using pre-assembled components in various shapes.  Straight lengths, 90° corner pieces, T and X shaped modules are all available.

At the heart of the Click! system is a 2835 type >90 CRI LED chip with an impressive output.  The modular pieces have been specially designed in order to produce a continous and dot-free light output, with no break in illumination.

  • 24Vdc 2835 LED chip - 220 per metre
  • >90 CRI (Colour Rendering Index)
  • IP20 - for interior use only
  • Opal diffuser
  • Dot-free and continuous illumination
  • Maximum 8 metres continuous run



From £11.38 £9.48
SKU
2835.1213*
SKU
2835.1213*

Plug & Play

The Click! modular strip LED system is very simple to assemble and install.  End caps can be easily removed with the special tool and junction connectors can then be used to fasten multiple modules together.  With Click!, a vast combination of designs can be brought to life without the need to cut, solder or worry about effective illumination at corners or junctions.



Visit our Accessories page to view the available connectors, fixing kits and other Click! essentials.

Continuous Illumination

The beauty of Click! is the seamless illumination across all junctions and between modules.  The LED chip arrangement means that there is no break in the chip spacing, even at a junction point.  The connectors cleverly feed power to the LED strips using contacts on the rear of the circuit boards, leaving space just for diodes.

Fixing Methods

Click! is magnetic.  Each modular piece has magnetic pieces integrated into the aluminium chassis.  This means that the product can be effortlessly held in place using the magnetic mounting plates.  For those who want added security, a traditional mechanical fixing solution is also available with discreet brackets.

Creative Components

Click! features an excellent choice of components which come together to create your creative lighting design.



L Section - Side Lens

L Section - Top Lens

L Section - Bottom Lens

T Section

X Section

Straight Section - Various Lengths



For our range of connectors and accessories, please visit the Click! accessories page





Drawings

Please see the below technical drawings for each of the component parts.

L Section - Side Lens

L Section - Top Lens

L Section - Top Lens

T Section

X Section





Video

More Information
Weight (kg)0.02
Light Element TypeSMD LED 12W/m
Lens Angle120°
Depth (mm)13.00
Input Voltage24Vdc
IP RatingIP20
DimmerYes
LEDs Per Metre220.00
CRI>90
Operating Temperature Range (°C)-25 ~ 45 °C
Strip LED TypeRigid Aluminium Profile
