Punch Marine 12" SVC 4-Ohm Subwoofer - Stainless Steel Grille - Black

The PM212SX is a white 12” subwoofer designed for marine watercraft or powersports applications. It features a color-matched luxury grille and is UV and moisture resistant. It can be used in sealed, vented or infinite baffle installations.
Special Price £179.20 £149.33 Regular Price £223.99
SKU
RF-PM212S4B
SKU
RF-PM212S4B

The PM212SX is a white 12” subwoofer designed with waterproof technology specific for marine watercraft or powersports applications. It features a color matched luxury grille and is UV and moisture resistant. It versatile design allows it to be used in sealed, vented or infinite baffle installations.



  • True Marine Grade compliance
  • 100% UV stable Centrex® injection molded plastic parts
  • Injection molded mineral filled polypropylene cone body with UV inhibitors
  • UV and Salt-Fog resistant TPE (Thermo-Plastic Elastomer) surround
  • 18 gauge corrosion resistant removable Stainless Steel grille cover insert
  • Ultra-flexible fully insulated silicone lead wire
  • Proprietary corrosion resistant spring loaded push terminals
  • Moisture, tear and fatigue resistant Aramid fiber spider
  • Linear, high excursion matched motor magnetics and suspension design
  • Internal magnetic shielding
  • Removable trim ring/grille
  • 2-Year Warranty
More Information
Weight (kg)9.16
ManufacturerRockford Fosgate
FinishBlack
Speaker Size12"
Speaker Impedance4-Ohms
Power Handling (Watts RMS)300 Watts RMS 600 Watts Max
Depth (mm)155.00
Speaker Input ConnectorDual 8 AWG compression
Fs (Hz)25.50
Cut-out Size (mm)Ø278.00
Qms9.00
Qts0.52
SPL (dB @ 1w/1m)87.00
Le (mH)0.30
Xmax (mm)12.00
Vas (Litres)44.30
Subwoofer Displacement (Litres)7.30
Voice Coil Diameter2" aluminum

Klippel Verified

Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

CEA-2031

CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

Element Ready™ - Subwoofers

Element Ready™ - Subwoofers

These subwoofers are protected against Dust, UV, Water, Corrosion, and feature Stainless hardware.

ASTM Test Standards

ASTM Test Standards

Marine Grade standards ensure resistance to extreme environments.



VAST Surround - Marine

VAST Surround - Marine

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

FlexFit Basket - Marine Sub

FlexFit Basket - Marine Sub

The slot mounted frame pattern allows fine-tuning of the subwoofer's mounting position.

Anodized Aluminum Voice Coil Former

Anodized Aluminum Voice Coil Former

Rockford Fosgate subwoofers use anodized aluminum voice coil formers for superior heat dissipation (up to 100° at full power levels).
