Punch Marine 12" SVC 4-Ohm Subwoofer - Stainless Steel Grille - Black
The PM212SX is a white 12” subwoofer designed with waterproof technology specific for marine watercraft or powersports applications. It features a color matched luxury grille and is UV and moisture resistant. It versatile design allows it to be used in sealed, vented or infinite baffle installations.
- True Marine Grade compliance
- 100% UV stable Centrex® injection molded plastic parts
- Injection molded mineral filled polypropylene cone body with UV inhibitors
- UV and Salt-Fog resistant TPE (Thermo-Plastic Elastomer) surround
- 18 gauge corrosion resistant removable Stainless Steel grille cover insert
- Ultra-flexible fully insulated silicone lead wire
- Proprietary corrosion resistant spring loaded push terminals
- Moisture, tear and fatigue resistant Aramid fiber spider
- Linear, high excursion matched motor magnetics and suspension design
- Internal magnetic shielding
- Removable trim ring/grille
- 2-Year Warranty
| Weight (kg) | 9.16 |
|---|---|
| Manufacturer | Rockford Fosgate |
| Finish | Black |
| Speaker Size | 12" |
| Speaker Impedance | 4-Ohms |
| Power Handling (Watts RMS) | 300 Watts RMS 600 Watts Max |
| Depth (mm) | 155.00 |
| Speaker Input Connector | Dual 8 AWG compression |
| Fs (Hz) | 25.50 |
| Cut-out Size (mm) | Ø278.00 |
| Qms | 9.00 |
| Qts | 0.52 |
| SPL (dB @ 1w/1m) | 87.00 |
| Le (mH) | 0.30 |
| Xmax (mm) | 12.00 |
| Vas (Litres) | 44.30 |
| Subwoofer Displacement (Litres) | 7.30 |
| Voice Coil Diameter | 2" aluminum |
Klippel VerifiedKlippel is a speaker certification program allowing us to deliver the best possible subwoofers. |
CEA-2031Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards. |
Element Ready™ - SubwoofersThese subwoofers are protected against Dust, UV, Water, Corrosion, and feature Stainless hardware. |
ASTM Test StandardsMarine Grade standards ensure resistance to extreme environments.
|
VAST Surround - MarineThe Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%. |
FlexFit Basket - Marine SubThe slot mounted frame pattern allows fine-tuning of the subwoofer's mounting position. |
Anodized Aluminum Voice Coil FormerRockford Fosgate subwoofers use anodized aluminum voice coil formers for superior heat dissipation (up to 100° at full power levels).
|
